Idromeccanica Forani & Pecorari (IFP) is a premier Italian engineering manufacturer specializing in heavy-duty, corrosion-resistant bronze seawater marine pumps and components. Established over 50 years ago, the company serves commercial fishing vessels, workboats, pleasure crafts, and various maritime or industrial installations. Because they utilize robust bronze hydraulic sections, these pumps excel at handling highly corrosive fluids, ensuring extended lifespans in demanding saltwater environments
- Monobloc / Close-Coupled Electric: Driven by a direct-coupled A.C. (primarily 3-phase) or D.C. electric motor.
- Bare Shaft: Built with a classic input shaft for direct mechanical link or PTO (Power Take-Off) configurations.
- Manual or Electromagnetic Clutch: Features built-in 12V or 24V clutches, allowing the crew to engage or disengage the pump remotely.
- Hydraulic Motor Drive: Integrated with oil-hydraulic motors for systems relying on central shipboard hydraulic pressure
Forani & Pecorari Hydraulic Motor Pumps
PC Selfpriming close coupled hydraulic motor pump unit
Description
The side channel PC pumps series with star impeller have an excellent self-priming capacity. For all models the direction of rotation can be reversed.
Application
– Diesel handling
– Sea and fresh water handling
– Bilge deckwash and general service duties
– Engine cooling
Materials:
Pump casing: bronze
Impeller: bronze
Shaft: stainless steel
Bearing Housing: grey cast iron
Mechanical seal: carbon/ceramic/NBR
Forani & Pecorari Hydraulic Motor Pumps
TS Selfpriming close coupled hydraulic motor pump unit
Description
The TS series consist of three sizes self-priming high performance side channel pumps.
Application
– Diesel handling
– Sea and fresh water handling
– Bilge deckwash and general service duties
– Engine cooling
Materials:
Pump casing: bronze
Impeller: bronze
Shaft: stainless steel
Bearing Housing: grey cast iron
Mechanical seal: carbon/ceramic/NBR
Forani & Pecorari Hydraulic Motor Pumps
AM Selfpriming close coupled hydraulic motor pump unit
Description
The AM pumps series are centrigugal selfpriming with double volute body, the smaller size (DN 40-50) can be supplied for clockwise or anti-clock rotation and are characterized by high flow.
Application
– Bilge deckwash
– Fire Prevention
– Ballast
– Conditioning units
Materials:
Pump casing: bronze
Impeller: bronze
Shaft: stainless steel
Bearing Housing: grey cast iron
Mechanical seal: carbon/ceramic/NBR
| Models (PDF) | Code | DN | Power Supply |
|---|---|---|---|
|
90-95000202 |
50 / 40 |
n/a |
|
|
90-95010302 |
65 / 50 |
n/a |
|
|
90-9500402 |
80 / 65 |
n/a |
Forani & Pecorari Hydraulic Motor Pumps
CM Close-coupled centrifugal pump with hydraulic motor
Description
The CM series pumps are single-stage centrifugal pumps with radial flow. They are available with clockwise or counter-clockwise rotation and are characterized by high flow rates.
Application
– Fire Fighting
– Ballast
– Air conditioning systems
Materials:
Pump casing: bronze
Impeller: bronze
Shaft: stainless steel
Bearing Housing: grey cast iron
Mechanical seal: carbon/ceramic/NBR
Forani & Pecorari Pumps with SAE Flange
PC Selfpriming pump with SAE flange
Description
The side channel PC pumps series with star impeller have an excellent self-priming capacity. For all models the direction of rotation can be reversed. All models can be supplied with two bolt SAE J744 flanged, size: A, B and C. On request, Forani & Pecorari s.n.c., can supply pumps with not standard contructive characteristics.
Application
– Diesel handling
– Sea and fresh water handling
– Bilge deckwash and general service duties
– Engine cooling
Materials:
Pump casing: bronze
Impeller: bronze
Shaft: stainless steel
Bearing Housing: grey cast iron
Mechanical seal: carbon/ceramic/NBR
| Models (PDF) | Code | DN | Power Supply |
|---|---|---|---|
|
90-9140310 |
25 |
n/a |
|
|
90-9600310 |
25 |
n/a |
|
|
90-9600810 |
32 |
n/a |
|
|
90-9611010 |
40 |
n/a |
Forani & Pecorari Pumps with SAE Flange
TS Selfpriming pump with SAE flange
Description
The TS pumps series with star impeller have an excellent self-priming capacity. For all models the direction of rotation can be reversed. All models can be supplied with two bolt SAE J744 flanged, size: B and C. On request, Forani & Pecorari s.n.c., can supply pumps with not standard contructive characteristics.
Application
– Diesel handling
– Sea and fresh water handling
– Bilge deckwash and general service duties
– Engine cooling
Materials:
Pump casing: bronze
Impeller: bronze
Shaft: stainless steel
Bearing Housing: grey cast iron
Mechanical seal: carbon/ceramic/NBR
| Models (PDF) | Code | DN | Power Supply |
|---|---|---|---|
|
90-9600412 |
40 |
n/a |
|
|
90-9610412 |
40 |
n/a |
|
|
90-9630412 |
40 |
n/a |
|
|
90-9600212 |
50 |
n/a |
|
|
90-9610212 |
50 |
n/a |
|
|
90-9600612 |
65 |
n/a |
